Mobile Electric Lifters
Lift, move and tilt with electric lifters
Application
Mobile Electric Lifters
- Lifting capacity: <250 kg
- IP-rating: IP24
- Stroke: 840-1910 mm
- Brake system: Central brake with directional lock (excl. PRO40)
- Battery charging procedure: 100-240V, grounded 50-0 Hz
- Up and down motion: 2-speed hand control (excl. PRO40)
Lift, move and tilt with electric lifters
Their innovative, modular design together with a wide selection of lifting Tools make TAWI Lifting Trolleys ideal for flexible and efficient material handling.
- Ergonomic handle to ensure good working position
- Safe and reliable for everyday use
- Modular design for easy adaptation to your needs
- Easily slide boxes from platform to shelf with platform rollers
- Easy to drive thanks to robust wheels
Application
Mobile Electric Lifters
Lift, move and tilt with electric lifters
Application
Mobile Electric Lifters
- Lifting capacity: <250 kg
- IP-rating: IP24
- Stroke: 840-1910 mm
- Brake system: Central brake with directional lock (excl. PRO40)
- Battery charging procedure: 100-240V, grounded 50-0 Hz
- Up and down motion: 2-speed hand control (excl. PRO40)
Lift, move and tilt with electric lifters
Their innovative, modular design together with a wide selection of lifting Tools make TAWI Lifting Trolleys ideal for flexible and efficient material handling.
- Ergonomic handle to ensure good working position
- Safe and reliable for everyday use
- Modular design for easy adaptation to your needs
- Lift and tilt crates to empty contents
- Lift and move crates to place in rack or shelf
- Easily slide boxes from platform to shelf with platform rollers
Application
Mobile Electric Lifters
Lift, move and tilt with electric lifters
Application
Mobile Electric Lifters
- Lifting capacity: <250 kg
- IP-rating: IP24
- Stroke: 840-1910 mm
- Brake system: Central brake with directional lock (excl. PRO40)
- Battery charging procedure: 100-240V, grounded 50-0 Hz
- Up and down motion: 2-speed hand control (excl. PRO40)
Lift, move and tilt with electric lifters
Their innovative, modular design together with a wide selection of lifting Tools make TAWI Lifting Trolleys ideal for flexible and efficient material handling.
- Ergonomic handle to ensure good working position
- Safe and reliable for everyday use
- Modular design for easy adaptation to your needs
- Lift and tilt crates to empty contents
- Lift and move crates to place in rack or shelf
- Easily slide boxes from platform to shelf with platform rollers
- Easy to drive thanks to robust wheels
Application
Mobile Electric Lifters
Lift, move and tilt with electric lifters
Application
Mobile Electric Lifters
- Lifting capacity: <250 kg
- IP-rating: IP24
- Stroke: 840-1910 mm
- Brake system: Central brake with directional lock (excl. PRO40)
- Battery charging procedure: 100-240V, grounded 50-0 Hz
- Up and down motion: 2-speed hand control (excl. PRO40)
Lift, move and tilt with electric lifters
Their innovative, modular design together with a wide selection of lifting Tools make TAWI Lifting Trolleys ideal for flexible and efficient material handling.
- Ergonomic handle to ensure good working position
- Safe and reliable for everyday use
- Modular design for easy adaptation to your needs
- Lift and tilt crates to empty contents
- Lift and move crates to place in rack or shelf
- Easily slide boxes from platform to shelf with platform rollers
- Easy to drive thanks to robust wheels
Application
Models and Technical Details
Model
Lifting capacity
Stroke mm short/medium/long
Weight of unit kg short/medium/long
Total height of unit mm
Battery charging procedure
Lifts per charge
Up and down motions
Front wheels
Brake System
Overload protection
PRO40
40 kg
-/1040/-
-/41/-
-/1640/-
100-240V, grounded 50-60 Hz
40kg x 1m x 100 times
Control panel (one speed)
Swivelling
Rear wheels separately braked
Incorporated in circuit load
PRO80
80 kg
850/1400/1950
46/50/53
1440/1990/2540
100-240V, grounded 50-60 Hz
80kg x 1m x 100 times
Hand control (two speed)
Swivelling
Central brake with directional lock
Incorporated in circuit load
PRO140
140 kg
840/1390/1940
69/73/78
1440/1990/2540
100-240V, grounded 50-60 Hz
140kg x 1m x 100 times
Hand control (two speed)
Fixed
Central brake with directional lock
Incorporated in circuit load
PRO180
180 kg
840/1390/1940
77/81/86
1440/1990/2540
100-240V, grounded 50-60 Hz
180kg x 1m x 100 times
Hand control (two speed)
Fixed
Central brake with directional lock
Incorporated in circuit load
Model
Lifting capacity
Stroke mm short/medium/long
Weight of unit kg short/medium/long
Total height of unit mm
Battery charging procedure
Lifts per charge
Up and down motions
Front wheels
Brake System
Overload protection
PRO250
250 kg
-/1360/1910
-/107/113 kg
-/1990/2540
100-240V, grounded 50-60 Hz
250kg x 1m x 100 times
Hand control (two speed)
Fixed
Central brake with directional lock
Incorporated in circuit load
PRO100ESE
100 kg
-/1390/1940
-/115/120 kg
-/1990/2540
100-240V, grounded 50-60 Hz
100kg x 1m x 100 times
Hand control (two speed)
Swivelling
Central brake with directional lock
Incorporated in circuit load
PRO200ESE
200 kg
-/1360/1910
-/152/158 kg
-/1990/2540
100-240V, grounded 50-60 Hz
200kg x 1m x 100 times
Hand control (two speed)
Fixed
Central brake with directional lock
Incorporated in circuit load
Stainless steel
Legs, wheels and handle in stainless steel. Equipped with a white FDA approved cover
Available for models PRO 140-250 including 100ESE and 200ESE
For technical details see sparepart model
